MSI Motherboard B760M GAMING PLUS WIFI – Intel
340,00 KM425,00 KM (-20%)
Garancija: 36 mjeseci(a)
MSI Motherboard B760M GAMING PLUS WIFI – Intel 14th/13th/12th Gen
| Chipset | Intel B760 |
| CPU podrška | Intel 12th Gen Processors Intel 13th Gen Processors Intel 14th Gen Processors |
| CPU podnožje | Socket 1700 |
| CPU Max. količina | 1 |
| Vrsta memorije | DDR5 SDRAM |
| Format memorije | DIMM 288-pin |
| Brzina memorije | 6800MHz(PC5-54400) |
| Max. kapacitet memorije | 256 GB |
| Količina utora | 4 |
| Provjera pogrešaka | non-ECC |
| Značajke memorije | Two DDR Channels Unbuffered Dual Rank Single Rank XMP |
| Integriran | Storage Controller: PCI Express 4.0 x4 (1 x M.2 (Key M)) Storage Controller: Supports: Level 0, Level 1, Level 10, Level 5 SATA III-600 (4) Wi-Fi Controller: 1 x M.2 (Key E) Storage Controller: PCIe 4.0 x4/SATA (1 x M.2 (Key M)) |
| Integrirani audio | Da |
| Vrsta | Integriran |
| Chipset | Realtek ALC897 |
| Audio izlaz | 7.1 Channel Surround |
| Audio standard | HD audio |
| Integrirani LAN | Da |
| LAN Chipset | Realtek Dragon RTL8125BG |
| Wi-Fi | IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n Wi-Fi 4 IEEE 802.11ac Wi-Fi 5 IEEE 802.11ax Wi-Fi 6E |
| Bluetooth | Bluetooth 5.3 |
| Podržana brzina | 2.5 Gbps |
| PCI Express x16 | 5 |
| USB 2.0 | 4 (USB 2.0 (type A)) |
| Antenna | 2 |
| USB 3.2 Gen 2 | 2 (USB 3.2 (type A)); 1 (USB 3.2 (type C)) |
| DisplayPort | 1 |
| HDMI | 1 (HDMI (Type A)) |
| LAN | 1 (RJ-45) |
| Audio izlaz | 5 (3.5-mm minijack) |
| S/PDIF-out Optical | 1 (TOSLINK) |
| PS/2 | 1 |
| Podržani operativni sustavi | Microsoft Windows 10 64-bit Microsoft Windows 11 64-bit |
| Kabeli | SATA Cable |
| Dodaci | I/O Shield Brzi priručnik WiFi antenna Screw |
| Format | ATX |
| Visina (mm) | 304.8 mm |
| Širina (mm) | 243.84 mm |
